KDE Connect and firewalld

So I was setting up KDE connect and I noticed that the default firewall setup on Fedora 23 blocks KDE connect. Fortunately, fixing it is simple. Just create a new service definition called kde-connect.xml like below and put it in /etc/firewalld/services

<?xml version="1.0" encoding="utf-8"?>
<service>
  <short>KDE Connect</short>
  <description>KDE Connect is a project that aims to communicate all your devices.</description>
  <port protocol="tcp" port="1714-1764"/>
  <port protocol="udp" port="1714-1764"/>
</service>

I had to restart firewalld to get it to recognize the new service file: systemctl restart firewalld.service. After that, just add the service like so: firewall-cmd --permanent --add-service kde-connect

Learned A New Trick Today

Today I had to record a serial number for an Ultrabook that had no serial number on the case anywhere. Turns out it was under the battery, but I found a better way:

wmic bios get serialnumber

Just thought I’d record that here for my future self.

Google's Guide for Technical Development

Google has an interesting guide on how to become a successful software engineer.

Five Problems Any Software Engineer Should be Able to Solve

Here’s an interesting article on five problems any software engineer should be able to solve.

I have to admit I’d have probably gotten the fourth one wrong and I’d be stuck on the fifth one. I’m a chemical engineer, so I guess I don’t need to worry, but I sure wish I was a software engineer.

I Ran 5k For The First Time

I managed to continuously run 5 km for the first time the other day. I’ve been working towards this for a couple months, so I’m pretty happy to finally be there. The Thunder Bay marathon is in September, and I’m hoping to at least be able to do a half marathon by then.

I ran 5k!

Mozilla SSL Server Configuration

Just a little note before I forget about this neat site I found a little while ago. Mozilla has a wiki page about recommended SSL configuration on various web servers. They also have a site that will generate a configuration based on your compatibility preferences. Seems pretty useful!

SHA256 in Enigmail

I’ve been moving away from using gmail recently, so I signed up for a hosted email provider and setup my new IMAP account in thunderbird along with the enigmail extension. I noticed after sending a few emails that enigmail defaults to using SHA-1 for hashing messages. That may be “good enough” for my uses, but I’d still like to use a stronger hashing function. I tried changing that in enigmail, only to find that the option is nowhere to be found. There is a way to force enigmail to use a stronger hash, but you have to edit your prefs.js file.

Close thunderbird, then add the following:

user_pref("extensions.enigmail.mimeHashAlgorithm", 3);

The enigmail documentation says the evailable options are:

  1. let GnuPG choose
  2. SHA-1
  3. RIPEMD160
  4. SHA256
  5. SHA384
  6. SHA512
  7. SHA224

It’s set to option 0 by default, but GnuPG picks SHA-1 for compatibility reasons. I opted for option 3: SHA256. Keep in mind that there’s probably some old software that will not be able to handle SHA256 floating around out there. Enigmail properly detected the SHA256 hash when I sent myself an email, so I decided to go with that.

Really Secure Shell

Came across an interesting article on configuring SSH to only use the strongest cryptographic functions available. Worth reading.

https://stribika.github.io/2015/01/04/secure-secure-shell.html

Owncloud on iSCSI

Introduction

Lately i’ve been working on setting up ownCloud on one of my virtual machines. I have grand schemes of having a storage server setup in the future, but monetary concerns dictate that my “storage server” is just another VM on the network.

I ran into a couple snags setting this up that weren’t immediately evident from googling my problems, so I thought I’d take the excuse to write a post about it. Most of this is from the Redhat documentation, and the Arch Wiki.

Target

The target is the storage server in iSCSI terms. RHEL 7 (and Fedora) have a handy tool for managing the target configuration called targetcli. You’ll need to install targetcli and enable it using systemd:

# yum install targetcli
# systemctl enable target.service
# systemctl start target.service

The built-in help is actually pretty helpful (try help) The tool is organized like a filesystem hierarchy where the different “directories” allow you to change various parts of the configuration. Tab completion works too.

Next you’ll need to create a backstore. In my case, I had an LVM volume which was added to the virtual machine as a disk: sda. If you’re using a different kind of backstore, then change the following command according to the Redhat documentation linked above.

/> /backstores/block
/backstores/block> create name=sda dev=/dev/sda

Next, create the iSCSI target:

/backstores/block> /iscsi
/iscsi> create
Created target
iqn.2003-01.org.linux-iscsi.freeze.x8664:sn.d34db33f
Created TPG1

Note that freeze is the hostname of the storage server.

Next step is to create a portal:

/iscsi> iqn.2003-01.org.linux-iscsi.freeze.x8664:sn.d34db33f/tpg1/
/iscsi/iqn.20...d34db33f/tpg1> portals/ create

It will create a portal that binds to all IP addresses (0.0.0.0). If you want to do something fancier, you’ll have to specifiy the ip address.

Create a LUN:

/iscsi/iqn.20...d34db33f/tpg1> luns/ create /backstores/block/sda

You can use ls to view a summary of the changes you’ve made.

Lastly, you need to create an ACL to allow your iSCSI client (initiator) to talk to your server (the target). To do that, you need to get the iSCSI qualified name of the initiator. This is auto-generated and stored in /etc/iscsi/initiatorname.iscsi. In this example, the target was iqn.2003-01.org.linux-iscsi.freeze.x8664:sn.d34db33f, and the initiator was iqn.1994-05.com.redhat:f33d.

/iscsi/iqn.20...d34db33f/tpg1> acls/
/iscsi/iqn.20...d34db33f/tpg1/acls> create iqn.1994-05.com.redhat:f33d

Firewall

The target service doesn’t install a service description file for firewalld, so I had to create one myself. Save the following as /etc/firewalld/services/iscsi.xml.

<?xml version="1.0" encoding="utf-8"?>
<service>
  <short>iSCSI</short>
  <description>iSCSI Target</description>
  <port protocol="tcp" port="3260"/>
</service>

Next, add the service to the default zone.

# firewall-cmd --add-service=iscsi
# firewall-cmd --permanent --add-service=iscsi

Initiator

First, install theiscsi-initiator-utils and enable the iscsid service.

# yum install iscsi-initiator-utils
# systemctl enable iscsid.service
# systemctl start iscsid.service

On the initiator, you should now be able to scan the target like so:

# iscsiadm -m discovery -t sendtargets -p freeze.home.lan
# 10.11.0.3:3260,1 iqn.2003-01.org.linux-iscsi.freeze.x8664:sn.d34db33f

Note that iscsiadm will tell you there’s no route to the host if it has trouble reaching the storage server (like if the firewall is denying traffic). This was one of the snags I ran into..

You should now be able to login to the target you just created.

# iscsiadm -m node -L all

This will create a device node that you can use to create a new filesystem. To find out what the device node is, you can run:

# iscsiadm -m session -P 3

Among other things, this will print out something like the following:

            Attached SCSI devices:
            ************************
            Host Number: 2  State: running
            scsi2 Channel 00 Id 0 Lun: 0
                    Attached scsi disk sda          State: running

Note that the created device was sda because my initiator is a virtual machine (so the virtual disk it uses as a hard drive is /dev/vda). If your initiator is not a VM, then the created device will probably be sdb. Also, the fact that the backing store on the target was sda is irrelevant.

You should be able to use fdisk to inspect the partition table on the device.

# fdisk /dev/sda

Create a filesystem if necessary.

# mkfs.ext4 /dev/sda

OwnCloud

Next, we’re going to setup the filesystem to mount at boot and move ownCloud’s storage onto the iSCSI device.

First, stop owncloud as we don’t want it writing to it’s index files while we’re moving things over.

# systemctl stop httpd.service

I opted to mount the filesystem by UUID so that it will still mount if the device is renamed for whatever reason.

Look in /dev/disk/by-uuid and see what points to sda. Take note of the UUID.

# ls -l /dev/disk/by-uuid

Now add the following to /etc/fstab:

UUID=insert_uuid_here /var/lib/owncloud ext4 defaults,_netdev       0 0

The _netdev option is important as it tells the init system to wait until the network is available before mounting the filesystem. The server will hang on boot without it.

I temporarily mounted the device to /mnt/tmp in order to copy over the owncloud data to it.

# mkdir /mnt/tmp
# mount /dev/sda /mnt/tmp
# cp -ar /var/lib/owncloud/* /mnt/tmp

Now we can unmount sda and remount it on /var/lib/owncloud.

# umount /mnt/tmp
# mount /var/lib/owncloud

Finally, we can restart owncloud.

# systemctl start httpd.service

That’s it! You should be able to access ownCloud again and have seamless remote storage. I should probably setup authentication for the iSCSI target, but as it’s running on a network that’s private to two virtual machines, I haven’t bothered. That’s on the TODO list.

First Post

Just setup this site using Hugo on Amazon S3/Cloudflare. I intend to post occasionally about interesting problems that i’ve solved, or neat stuff that i’ve created.

I’ve been thinking of getting my RHCE certification, so I’ve been spending a bunch of time lately setting up a virtualized FreeIPA domain for my home network as practice. I’ll probably be posting about that, in addition to the creation of this website.
